ACSR Self-supporting ABC Cable 0.6/1kV XLPE Insulated Aerial Bundled Overhead Power Cable
| High Light: | XLPE Insulated ABC Cable,ACSR Self-supporting Aerial Bundled Cable,0.6/1kV Overhead Power Cable |
||
- Primary and secondary distribution networks
- Industrial power supply lines
- Renewable energy projects (solar/wind farm connections)
- Infrastructure developments requiring reliable overhead cabling
Conductor Screen: Extruded Semi-conductive Layer
Insulation: XLPE
Insulation Screen: Extruded Semi-conductive Layer
Metallic Screen: Copper wire screen or copper tape screen
Outer Sheath: HDPE
Support Conductor: Galvanized steel wires
| Description | Phase Conductor | Bare Conductor (ACSR) | Approx. Overall Diameter & Weight |
|---|---|---|---|
| 1*10mm²+10mm² | 7/1.35 | 6/1.35 | 10.30mm / 858kg/km |
| 1*16mm²+16mm² | 7/1.70 | 6/1.70 | 12.84mm / 133.7kg/km |
| 1*25mm²+25mm² | 7/2.22 | 6/2.22 | 15.04mm / 215.8kg/km |
| 1*35mm²+35mm² | 7/2.59 | 6/2.59 | 17.8mm / 294.0kg/km |
| 1*50mm²+50mm² | 7/3.10 | 6/3.10 | 19.68mm / 410.2kg/km |
| 1*70mm²+50mm² | 19/2.22 | 6/3.10 | 21.38mm / 574.3kg/km |
| 1*95mm²+50mm² | 19/2.59 | 6/3.10 | 22.98mm / 704.5kg/km |
| 2*10mm²+10mm² | 7/1.35 | 6/1.35 | 12.30mm / 120.7kg/km |
| 2*16mm²+16mm² | 7/1.70 | 6/1.70 | 15.24mm / 133.7kg/km |
| 2*25mm²+25mm² | 7/2.22 | 6/2.22 | 17.44mm / 310.2kg/km |
| 2*35mm²+35mm² | 7/2.59 | 6/2.59 | 20.28mm / 422.5kg/km |
| 2*50mm²+50mm² | 7/3.10 | 6/3.10 | 22.48mm / 594.2kg/km |
| 2*70mm²+50mm² | 19/2.22 | 6/3.10 | 25.88mm / 964.5kg/km |
| 2*95mm²+50mm² | 19/2.59 | 6/3.10 | 29.08mm / 1224.9kg/km |
| 3*10mm²+10mm² | 7/1.35 | 6/1.35 | 14.76mm / 187.6kg/km |
| 3*16mm²+16mm² | 7/1.70 | 6/1.70 | 18.28mm / 290.4kg/km |
| 3*25mm²+25mm² | 7/2.22 | 6/2.22 | 20.92mm / 458.6kg/km |
| 3*35mm²+35mm² | 7/2.59 | 6/2.59 | 24.33mm / 625.0kg/km |
| 3*50mm²+50mm² | 7/3.10 | 6/3.10 | 26.97mm / 862.3kg/km |
| 3*70mm²+50mm² | 19/2.22 | 6/3.10 | 31.05mm / 1354.7kg/km |
| 3*95mm²+50mm² | 19/2.59 | 6/3.10 | 34.89mm / 1745.3kg/km |
-
