Home > Products> Low Smoke Zero Halogen Cable> Fire Protection LSZH Cable Three Core MV 8.7/15kV XLPE Insulated Steel Tape Armored PVC Sheathed Cable

Fire Protection LSZH Cable Three Core MV 8.7/15kV XLPE Insulated Steel Tape Armored PVC Sheathed Cable

Basic Information

Place of Origin:	Hebei，China
Brand Name:	Fire Protection LSZH Cable
Certification:	IEC,CE,ISO,TUV
Model Number:	NYBY NAYBY

Minimum Order Quantity:	Negotiable
Price:	Negotiable
Packaging Details:	Rolls, Wooden Drums, Steel Drums, Reels or customized
Delivery Time:	7-30 days based on different qty
Payment Terms:	,L/C,T/T
Supply Ability:	100KM/Week

Get Best Price Contact Now

Detail Information

Voltage:	3.6/6kV	Insulation:	XLPE
Jacket:	PVC	Feature:	LSZH
Amour:	Steel Tape	Application:	Underground, Overhead, Indoor, Mining And Power Distribution Etc
Highlight:	LSZH fire protection cable , three core MV XLPE cable , steel tape armored PVC cable

Product Description

Fire Protection LSZH Cable Three Core MV 8.7/15kV XLPE Insulated Steel Tape Armored PVC Sheathed Cable

Product Overview

Fire Rated Low Voltage Wire with 3 Core 1.5-400mm² is engineered to maintain circuit integrity during fire conditions, ensuring continuous power supply for critical emergency systems.

Applications

Suitable for power supply lines with flame retardant requirements, such as urban underground power grids, power station outgoing lines, and internal power lines of industrial and mining enterprises.

Construction Details

Conductor:Tightly press circular conductor
Conductor shield:Semi conductive shielding material (below 500mm ²) Semi conductive tape+semi conductive shielding material (500mm ² and above)
Insulation:XLPE
Insulation shielding: Peelable semiconducting shielding material
Metal shielding layer: Copper Tape
Filler: Non hygroscopic filling rope
Binder Tape:Non hygroscopic straps
Armor:3 core: galvanized steel tape
Inner and outer sheath:90 ℃ flame retardant polyvinyl chloride

Technical Characteristics

Voltage Rating Uo/U: 8.7/15(17.5)kV
Maximum operating temperature of conductor: +90℃
Operating ambient temperature: -20℃ to +45℃
Cable laying temperature: Not less than 0℃ (Preheating required below 0℃)
Minimum Bending Radius: 12D

Specifications

Specs mm²	Conductor diameter mm	Nominal thickness of insulation ±1.0mm	Approx outer diameter of cable mm	Approx cable weight kg/km
3×25	5.6±0.1	17.2	47.3	3168
3×35	6.6±0.2	18.2	49.7	3609
3×50	7.6±0.2	19.2	52.2	4152
3×70	9.2±0.2	20.8	55.8	4988
3×95	10.9±0.2	22.5	60.0	6051
3×120	12.2±0.2	23.8	63.1	6976
3×150	13.6±0.2	25.2	66.3	8038
3×185	15.2±0.2	26.8	70.1	9343
3×240	17.4±0.2	29.0	75.4	11343
3×300	19.5±0.2	31.1	81.6	14262
3×400	22.0±0.2	33.6	87.5	17106
3×500	24.8±0.2	37.2	95.8	21121
3×630	28.2±0.2	40.6	104.0	25921

Manufacturing Facility

Application Examples

Company Profile

Industry Partners

Frequently Asked Questions

Q1: Are you trading company or manufacturer?

A1: We are manufacturer and trading company.

Q2: Do you have your own R&D team?

A2: Yes, we can customize products as your requirements.

Q3: How about the quality?

A3: We have the best professional engineer and strict QA and QC system.

Q4: Can we be your distributor?

A4: We are looking for distributor and agent all over the world.

Q5: What quality certifications do you hold?

A5: We have obtained ISO and CCC quality management system certifications, and some products have also obtained international certifications. We can also apply for specific certifications based on customer requirements.

Q6: What is the delivery lead time?

A6: Standard products are typically in stock and can be shipped within 7-15 days. Customized products require 15-45 days depending on quantity.

Q7: Do you accept customized products?

A7: We provide OEM and ODM service, we can customize cable products according to customer's special requirements, including specifications, colors, packaging and so on.
