Medium Voltage Industrial Power Cable 25-630mm2 sectional Area IEC60502 for Industrial Power Installations

Medium Voltage Industrial Power Cable 25-630mm2 sectional Area IEC60502 for Industrial Power Installations

APPLICATION

Single Core MV (Medium Voltage) Power Cable with Copper Tape Screen (CU/XLPE/CTS/PVC) is primarily designed for power transmission and distribution in medium voltage networks, typically operating within the 1kV to 35kV range. Its applications include underground installations, outdoor environments, and cable ducting systems, where reliable performance under challenging conditions is required.

CONSUCTRUCTION

• Conductor:Class 2 Stranded Copper
• Conductor Screen:Semi-conductive material
• Insulation: XLPE (Cross-Linked Polyethylene)
• Insulation Screen:Semi-conductive material (bonded)
• Longitudinal Water blocking Semi-conductive swellable tape
• ScreenZ: Copper wires and copper tape
• Outer Sheath PVC

CHARACTERISTIC

Voltage Rating Uo/U:8.7/10(12)kV,8.7/15(17.5)kV

Maximum operating temperature of conductor:+90℃

Operating ambient temperature: -20℃~+45℃

Cable laying temperature:Not less than 0℃(When the ambient temperature is below 0℃, the cable should be preheated.)

Minimum Bending Radius: 15D

SPECIFICATION

CONTACTR US FOR MORE VOLATAGE
