ACSR Wolf Bare Conductor for Overhead Transmission Lines
| Range Of Application: | Overhead Transmission, Overhead Ground | Material: | ACSR |
| Drum Packing: | Steel Wooden Drum | Product Name: | ACSR Wolf Conductor |
| Type: | BARE Conductor | Standard: | IEC, BS, ICEA, ASTM, DIN |
| High Light: | Rabbit ACSR Bare Conductor,Dog ACSR Bare Conductor,Overhead Transmission ACSR Bare Conductor |
||
ACSR Wolf Bare Conductor for Overhead Transmission Lines
APPLICATION
- ACSR Wolf Bare Conductor is primarily used in overhead power transmission lines for efficient electricity distribution. Its design combines aluminum layers for conductivity and a galvanized steel core for mechanical strength, making it suitable for long-distance transmission across various terrains, including rivers and valleys.
- The conductor operates under high temperatures (up to 95°C) and complies with standards like ASTM B232/BS 215/IEC 61089.
- It is widely adopted in utility grids due to its high tensile strength, corrosion resistance, and cost-effectiveness
CONSUTRUCTION
- ACSR is concentrically stranded conductor with one or more layers of Aluminium wire hard-drawn 1350-H19 on the galvanized steel wire core. The core may be single wire or stranded depending on the size. Steel wire is available in Class A or B galvanization as corrosion protection.
- ACSR is according to electrical and mechanical strength requirements of transmission or distribution lines, can provides an appropriate design combining the quantity of Aluminium and galvanized steel wires.
STANDARD
IEC, BS, ICEA, ASTM, DIN
SPECIFICATION
ABOUT US
OUR WAREHOUSE
APPLICATION
Q: What is the core material of ACSR Wolf Bare Conductor?
A: It features a galvanized steel core for high tensile strength and aluminum layers for efficient conductivity.
Q: Where is ACSR Wolf Bare Conductor typically used?
A: Designed for overhead power transmission lines, especially in long-distance applications across diverse terrains.
Q: What temperature range can this conductor withstand?
A: Operates effectively under high temperatures, with specifications often reaching up to 95°C.
Q: How does the conductor handle mechanical stress?
A: The steel core resists external loads like wind and ice, while aluminum layers maintain flexibility for installation.
Q: Is ACSR Wolf Bare Conductor resistant to corrosion?
Yes, its aluminum surface forms a protective oxide layer, and the galvanized steel core resists environmental degradation.
Q: Can it be used in high-voltage transmission systems?
A: Absolutely, it’s widely adopted in utility grids due to its balance of conductivity and strength.
Q: How does its design benefit power transmission?
The combination of lightweight aluminum and robust steel core minimizes energy loss and supports longer spans.
Q: What maintenance requirements does it have?
Low maintenance due to corrosion resistance, reducing the need for frequent inspections.
-
