8.7KV 15kV Medium Voltage Cable Low Smoke Zero Halogen LSZH Fire Resistant
| Voltage: | 8.7/ 15kV | Insulation: | XLPE |
| Jacket: | PVC | Feature: | LSZH |
| Amour: | Steel Tape | Application: | Underground, Overhead, Indoor, Mining And Power Distribution Etc |
| High Light: | LSZH 15kV Medium Voltage Cable,Fire Resistant Medium Voltage Cable |
||
Low Smoke Zero Halogen Medium Voltage Cable LSZH Fire Resistant 8.7/15kV
Application
- Urban Infrastructure:Underground power distribution networks in cities, tunnels, and subways where fire resistance and low smoke emission are critical for evacuation and rescue.
- Commercial and High-Rise Buildings:Main power supply systems, emergency circuits, and riser shafts in offices, hotels, and residential towers to comply with strict fire safety regulations.
- Public Transportation Hubs:Rail stations, airports, and bus terminals for medium-voltage power feeds to lighting, signaling, and ventilation systems in crowded or enclosed spaces.
- Industrial Complexes:Petrochemical plants, mining sites, and manufacturing facilities requiring flame-retardant cables that minimize corrosive fumes during electrical faults or fires.
- Renewable Energy Installations:Wind farms and solar parks for connecting medium-voltage transformers and inverters, especially in environmentally sensitive areas.
- Hospitals and Data Centers:Critical power backup systems and distribution networks where LSZH materials prevent hazardous smoke from damaging sensitive equipment or endangering lives.
- Marine and Offshore:Ships, oil rigs, and ports for fire-safe power distribution in confined or high-risk environments.
Construction
- Conductor :Class 2 stranded copper conductor
- Insulation :XLPE (Cross-Linked Polyethylene)
- Bedding :LSZH (Low Smoke Zero Halogen)
- Armour :STA (Steel Tape Armour)
- Sheath :LSZH (Low Smoke Zero Halogen)
Advantage
- Composite high temperature resistance performance
- Compressive and tensile strengthening
- LSZH jacket
- Anti bending and anti deformation
- Electromagnetic and Environmental Adaptability
- Low frequency interference shielding
- Chemical corrosion protection
- Direct burial without conduit
- Extended lifespan
Specification
|
Specification |
Outer diameter |
Approx. outer diameter of cable |
Approx. weight of cable |
Max. D.C. resistance of conductor at 20℃ |
||
|
mm2 |
mm |
mm |
kg/km |
Ω/km |
||
|
|
|
|
Cu |
Al |
Cu |
Al |
|
1×25 |
6 |
22.2 |
686.9 |
532.2 |
0.727 |
1.2 |
|
1×35 |
7 |
23.2 |
806.6 |
590.1 |
0.524 |
0.868 |
|
1×50 |
8.4 |
24.6 |
983 |
673.7 |
0.387 |
0.641 |
|
1×70 |
10 |
26.2 |
1210.1 |
777 |
0.268 |
0.443 |
|
1×95 |
11.5 |
27.7 |
1482.7 |
894.9 |
0.193 |
0.32 |
|
1×120 |
13 |
29.3 |
1757.8 |
1015.4 |
0.153 |
0.253 |
|
1×150 |
14.5 |
30.9 |
2078.2 |
1150.1 |
0.124 |
0.206 |
|
1×185 |
16.2 |
32.7 |
2450.5 |
1305.9 |
0.0991 |
0.164 |
|
1×240 |
18.4 |
35.1 |
3021.2 |
1536.4 |
0.0754 |
0.125 |
|
1×300 |
20.5 |
37.3 |
3633.6 |
1777.5 |
0.0601 |
0.1 |
|
1×400 |
23.5 |
40.5 |
4639.5 |
2164.7 |
0.047 |
0.0778 |
|
1×500 |
26.5 |
43.7 |
5644.9 |
2551.4 |
0.0366 |
0.0605 |
|
1×630 |
30 |
47.4 |
6940.2 |
3042.4 |
0.0283 |
0.0469 |



-
