Tinned Copper Solar Cable with XLPO Insulation and Halogen-Free Sheath for Photovoltaic Applications
| Insulation Material: | Xlpe | Jacket: | XLPO |
| Conductor Material: | Class 5 Tinned Copper | Application: | Construction |
| Core: | 1 Core | Colour: | Black /Other Colours Available On Request |
| High Light: | Copper Core Solar Cable PVC Insulated,H1Z2Z2-K PVC Sheathed Power Cable |
||
• Interconnection between photovoltaic modules
• Parallel connection between series and between modules and DC distribution boxes (combiner boxes)
• Connection between DC distribution boxes and inverters
• Connecting inverters to step-up transformers
• Connection between step-up transformers and distribution equipment
• Connection between power distribution equipment and the power grid or users
- Fire Resistance
- Low Smoke and Toxicity
- High-Quality Insulation Materials
- Exceptional Durability
- Full Regulatory Compliance
Insulation: Cross-linked polyethylene (XLPO) or similar material, providing high thermal and mechanical resistance
Sheath: Halogen-free, flame-retardant material, ensuring safety and environmental compliance
| Cross Section (mm²) | Conductor Construction (no/mm) | Conductor Stranded OD.max (mm) | Cable OD. (mm) | Approximate Weight of Cable (kg/km) | Max Conductor Resistance (Ω/km, 20°C) |
|---|---|---|---|---|---|
| 1×1.5 | 48/0.20 | 1.58 | 4.8 | 35 | 13.7 |
| 1×2.5 | 77/0.20 | 2.02 | 5.2 | 47 | 8.21 |
| 1×4 | 56/0.285 | 2.46 | 5.7 | 64 | 5.09 |
| 1×6 | 84/0.285 | 3.01 | 6.3 | 86 | 3.39 |
| 1×10 | 77/0.40 | 4.1 | 7.2 | 128 | 1.95 |
| 1×16 | 7×17/0.40 | 5.5 | 8.9 | 196 | 1.24 |
| 1×25 | 7×27/0.40 | 6.7 | 10.7 | 299 | 0.795 |
| 1×35 | 7×38/0.40 | 8.2 | 12.4 | 407 | 0.565 |
| 1×50 | 19×20/0.40 | 10.0 | 14.6 | 571 | 0.393 |
| 1×70 | 19×28/0.40 | 11.6 | 16.4 | 773 | 0.277 |
| 1×95 | 19×38/0.40 | 13.5 | 18.5 | 1024 | 0.210 |
| 1×120 | 24×38/0.40 | 14.4 | 19.8 | 1266 | 0.164 |
| 1×150 | 30×38/0.40 | 16.2 | 22.2 | 1584 | 0.132 |
| 1×185 | 37×38/0.40 | 18.2 | 25.0 | 1967 | 0.108 |
| 1×240 | 48×38/0.40 | 20.6 | 27.8 | 2518 | 0.0817 |
-
